Large electrical capacity, long life & high reliability;

Accurate tripping off time, prevent motor temperature from being too high;

Both temperature and current sensing.

125V AC / 250V AC : 5~90A

12V DC / 24V DC : 5~120A

Trip off current range: 5~120A

Trip off time under R/T 25℃: 4~10S (Or Customized)

Temperature Protection:

When ambient temperature exceeds the specified value, the inside bimetal of 8AME series will trop off to cut the circuit. When the temperature lowers down, the bimetal will reset and the circuit is connected again.

Current Protection:

Auxiliary heater works together with bimetal, which can control the trip off time precisely. When the current exceeds the prescribed value, 8AME will cut the circuit immediately.

Electrical tools          Mixer                 Sinking pump          High pressure washer

Split phase motor     Oil pump          Car motor                 Washing machine

Dust collector            Ballasts              Transformer           Large water pump          Capacitor start motor
